Model: TRX500FM
Engine Type: 475cc single-cylinder four-stroke
Bore and Stroke: 92mm x 71.5mm
Ignition: CD with electronic advance
Starter: Electric with auxiliary recoil
Clutch: Automatic
Transmission: Five-speed with reverse
Driveline: Direct front and rear drive-shafts with TraxLok and torque-sensitive front differential
Suspension Front: Independent double-wishbone; 6.7 inches travel
Rear: Swingarm with dual shocks; 6.7 inches travel
Brakes Front: Dual hydraulic 180mm disc
Rear: Sealed 180mm mechanical drum
Tires Front: 25 x 8-12
Rear: 25 x 10-12
Length: 83.0 inches
Width: 46.7 inches
Height: 46.3 inches
Seat Height: 33.9 inches
Ground Clearance: 7.5 inches
Wheelbase: 50.7 inches
Turning Radius: 10.8 feet
Dry Weight: 592 pounds (TRX500FE)
Fuel Capacity: 4.2 gallons, including 0.79-gallon reserve
